All of our custom-made, low-loss cable assemblies are made in the USA with PT240, 50 ohm coaxial cable.  These cables are typically in-stock, or made to order, and ship same-day or next-day. Recommended for use with frequencies from 150 MHz - 5 GHz.  At 900 MHz or higher we do not recommend using cable lengths over 50 feet.  For 900 MHz and up, at lengths longer than 50 feet, we suggest uppgrading to PT400 type cable assemblies.

Want to build a custom coax cable? Use our Coax Builder!

Mechanical Specifications:

• Outside Diameter: 0.240 inches
• Outside Jacket: Black, PVC (estimated 20 year service life)
• Insulation: Foamed Polyethelyne
• Center Conductor: solid copper (1.42 mm)
• Bend Radius: 19.1mm
• Appropriate for indoor or outdoor use (at -40 to +85 C)

 Attenuation/Low Chart (dB loss per 100 feet)

• 150 MHz (VHF) 3.02 dB
• 450 MHz (UHF) 5.27 dB
• 900 MHz (ISM)  7.56 dB
• 1800 MHz (3G) 10.85 dB
• 2.4 GHZ (WiFi) 12.92 dB
• 5.8 GHZ (WiFi) 20.40 dB

 LMR® is a Registered Trademark of Times Microwave Systems.
