RYE-4-11-SNF
Log Periodic Enclosed Yagi Antenna 3G/4G/LTE High Performance Wide Band
- Broadband 880-960 MHz Yagi antenna optimized for SCADA, ISM, and 900 MHz spread spectrum applications
- 7-element directional design with 12.2 dBi gain for reliable long-range, point-to-point connectivity
- IP67-rated, gold anodized construction with 360° welded elements for superior weatherproofing and corrosion resistance
- Supports up to 200W input power with 136 MPH wind survival rating for extreme outdoor deployments
- Includes N-Female connector, 19 cable, and mounting kit for easy installation
- Compatible with leading platforms including Digi, Freewave, Microhard, MultiTech, and MDS Orbit
- Cost-effective, in-stock alternative to Kathrein TY-900, backed by a 5-year warranty
Technical Specifications
| SKU | RYE-4-11-SNF |
|---|---|
| Manufacturer | RFMAX |
| Color | White |
| Connector 1 | N-Female |
| Directional or Omni | Directional |
| Working Frequency | 698-960 MHz |
| Working Frequency 2 | 1710-2700 MHz |
| Antenna Category | 4G/LTE (698-2700 MHz) |
| Gain | 8.5 dBi |
|---|---|
| Gain 2 | 9.5 dBi |
| Ground Plane Required | No |
| Material | ABS Anti UV |
| Max Input Power (W) | 100 W |
| Operating Temp (celsius) | -40 to 55 |
| VSWR: < X: 1 | 1.4 |
| Weight (lbs) | 1.8 |
