R4WA-G454W-10-S4S4R-B
9 in 1, No Drilling- Adhesive Mount "Wedge" Antenna for Dashboard/Windshield 10 ft Cable, 4x 5G/LTE, 4x WiFi-6E, 1x GNSS
- This is a high-performance, 9-in-1 covert antenna solution optimized for the latest 5G and Wi-Fi 6E application
- 4x 5G/4G/LTE, 4x WiFi-6E, and 1x GNSS ports -10 Ft cables
- offers high-speed data, low-latency wireless, and precise location tracking
- Engineered for next-generation connectivity, it supports wideband frequencies, including 5G-FR1, WiFi-6E, and GNSS, ensuring compatibility with major North American carriers
- Compatible with Ericsson/Cradlepoint Modem / Gateway / Router R980, R1900, IBR1700, IBR900, Semtech Airlink XR-90, XR-80, MG-90, MP-70, Peplink UBR Plus, & MB series Radios etc.
Technical Specifications
| SKU | R4WA-G454W-10-S4S4R-B |
|---|---|
| Manufacturer | RFMAX |
| Cable Length (inches) | 120 |
| Cable Type | LL-195/RG-174 |
| Color | Black |
| Connector 1 | SMA-Male |
| Connector 2 | RP SMA-Male |
| Connector 3 | SMA-Male |
| Directional or Omni | Omni Directional |
| Working Frequency | 617-7125 MHz |
| Working Frequency 2 | 2400-7125 MHz |
| Antenna Category | Multi-Band (Cellular, WiFi, and/or GPS) |
| Gain | 3.6 - 4.6 dBi |
| Gain 2 | 3.9-4.6 dBi |
| Height/Length (inches) | 8.66 inches |
|---|---|
| Height/Length (mm) | 220 |
| OK for Outdoor Use | Indoor |
| IP Rating | IP65 |
| Max Input Power (W) | 2 Watts |
| Mount Style | Adhesive Mount |
| No Of Elements | 9 |
| Number of Cables | 9 |
| Operating Temp (celsius) | -40°C to + 85°C |
| VSWR: < X: 1 | <2.0:1 |
| Weight (grams) | 420g |
| Width (inches) | 3.15 inches |
| Width (mm) | 80 |
