Advantages and Disadvantages of PT195. PT240, and PT400

0 Comments | Posted on
Advantages and Disadvantages of PT195. PT240, and PT400
  Advantages Disadvantages
PT195: Recommended for use with frequencies under 900 MHz
  • Lower loss than standard RG58 cable
  • The most flexible



  • Less flexible than the RG58
  • Too much attenuation/ loss for frequencies over 900 MHz
  • Don’t recommend using cable lengths over 15-20 ft. at 900 MHz
PT240: Recommended for use with frequencies from 150 MHz – 5 GHz



  • Much lower loss and higher performance than standard RG58 and PT195 cable
  • Flexible
  • Excellent for UHF RFID
  • Much less flexible than RG58 and PT195
  • Too much attenuation/ loss for frequencies over 900 MHz at lengths of 50+ ft.
PT400: Recommended for use with frequencies from 150 MHz – 5 GHz



  • Extremely low-loss and high performance
  • Relatively inexpensive due to high sale volumes
  • The least flexible of the three



Note: All cable assemblies are made to order and typically ship in 1-2 business days from the time we receive the order. Larger quantities may require longer lead times.

For our Custom Cable Builder click here!

For further information regarding the application of this product, you can always reach out to our tech support!

Tech Help at RFMAX / rfmax.us can be reached by email at rfcustomerservice@rfmax.us
